brick machine automatic

Modern construction demands efficiency and consistency, which is why a high-performance auto brick machine has become the backbone of large-scale masonry projects. Our engineering team has refined every aspect of the automatic cement brick machine to deliver unmatched output while minimizing manual labor. As a versatile brick building machine, it accommodates a wide range of molds and raw materials, from fly ash to crushed stone. This positions it as the go-to brick making machine for contractors who need reliable, uniform blocks for structural walls, pavers, and hollow bricks alike.

The Fully Automatic Brick Machine redefines production workflows by integrating smart controls with a heavy-duty hydraulic system. It senses material consistency in real time and adjusts pressing pressure to ensure every brick meets compressive strength targets beyond 25 MPa. Operators monitor cycle times and fault diagnostics through a touchscreen HMI without interrupting continuous feeding or stacking. With vibration-assisted compaction and synchronized pallet feeding, this machine consistently cycles within 12–15 seconds, making it ideal for plants targeting 10,000 to 30,000 bricks per shift. Its modular mold-change system reduces downtime to under 20 minutes, allowing rapid switchover between solid, hollow, and interlocking designs.

Core Technical Parameters

• Forming cycle: 12–15 seconds per pallet (adjustable via PLC)
• Pressing force: 120–200 kN hydraulic, serviced by dual variable displacement pumps
• Vibration: Two synchronized eccentric shafts with 4,500 N centrifugal force each
• Mold variants: interchangeable molds for solid brick (240×115×53 mm), hollow block (400×200×200 mm), paver (200×100×60 mm), and curbstone
• Pallet size: 900×650 mm high-strength steel, magazine capacity 24–36 pallets
• Control system: Siemens S7-1200 PLC with 7-inch color touchscreen, multilingual interface and remote monitoring option
• Energy consumption: 22–30 kW total installed power, including mixer and conveyor interface
• Raw materials: cement, sand, gravel, fly ash, slag, stone powder, with water-cement ratio tolerance ±0.02
• Dimension and weight: 4,800×2,200×2,900 mm (L×W×H), approximately 5.8 tons
• Certifications: CE, ISO 9001, safety interlock guarding per EN 12001
